parse.h File Reference

Function headers for parsing and operator precedence values. More...

#include "tree.h"
#include "types/number.h"

Include dependency graph for parse.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Functions
ASTNode *	parse_binary_expression (void)
	Convenience wrapper for parse_binary_expression_recursive. More...
void	match_token (TokenType type)
	Ensure current token is of a given type, and scan the next token if so. More...
int	match_type (Number *out)
	Matches a valid type in the input stream. More...
TokenType	check_for_type (void)
	Ensure current token is a type token, and scan the next token if so. More...
void	variable_declaration (void)
	Parse a variable declaration statement into an AST. More...
ASTNode *	function_declaration (void)
	Parse a function declaration statement into an AST. More...
ASTNode *	function_call_expression (void)
	Parse a function call expression into an AST. More...
ASTNode *	parse_statements (void)
	Parse a set of statements into ASTs and generate them into an AST. More...

Variables
static TokenType	operatorPrecedence []
	Operator precedence values. Precedence ranges from 0-15, 15 being the first to be computed. More...
static TokenType	rightAssociativeOperators [TOKENTYPE_MAX+1]

Detailed Description

Function headers for parsing and operator precedence values.

Author

Charles Averill

Date

09-Sep-2022

Operator Precedence

This table outlines Purple's operator precedence values. A higher precedence value is computed before a lower precedence value.

Precedence	Operator	Description	Associativity
16	++ -- () [] . -> (type){list}	Postfix increment/decrement Function call Array subscript Structure and Union member access Structure and union pointer member access Compound literal	Left-to-Right
15	** ++ -- - ! ~ (type) * & bytesize	Exponent Prefix increment/decrement Unary negative Logical NOT, bitwise NOT Cast Dereference Address-of Size in bytes	Right-to-Left
14	* / %	Multiplication, division, modulus	Left-to-Right
13	+ -	Addition, Subtraction
12	<< >>	Bitwise shifts
11	< <= > >=	"Less than", "Less than or equal to" relational operators "Greater than", "Greater than or equal to" relational operators
10	== !=	"Is equal", "Is not equal" relational operators
9	&	Bitwise AND
8	^	Bitwise XOR
7	|	Bitwise OR
6	and nand	Logical AND Logical NOT-AND
5	xor xnor	Logical XOR Logical NOT-XOR
4	or nor	Logical OR Logical NOT-OR
3	? ... :	Ternary condition	Right-to-Left
2	= += -= *= /= %= <<= >>= &= |= ^=	Assignment Sum, Difference Assignments Product, Quotient, Modulus Assignments Bitshift Assignments Bitwise AND, OR, XOR Assignments
1	,	Comma	Left-to-Right

Function Documentation

check_for_type()

TokenType check_for_type

(

void

)

Ensure current token is a type token, and scan the next token if so.

Returns

NumberType Type of variable

function_call_expression()

ASTNode * function_call_expression

(

void

)

Parse a function call expression into an AST.

Returns

ASTNode* AST Node containing function call data

function_declaration()

ASTNode * function_declaration

(

void

)

Parse a function declaration statement into an AST.

Returns

ASTNode*

match_token()

void match_token

(

TokenType

type

)

Ensure current token is of a given type, and scan the next token if so.

Parameters

type	TokenType to ensure

match_type()

int match_type

(

Number *

out

)

Matches a valid type in the input stream.

Parameters

out	Pointer to Number struct to fill with parsed data

Returns

int 0 if out is filled properly, 1 if the scanned type is "void"

parse_binary_expression()

ASTNode * parse_binary_expression

(

void

)

Convenience wrapper for parse_binary_expression_recursive.

Returns

ASTNode* An AST or AST Subtree of the binary expressions in D_INPUT_FILE

parse_statements()

ASTNode * parse_statements

(

void

)

Parse a set of statements into ASTs and generate them into an AST.

Returns

AST for a group of statements

variable_declaration()

void variable_declaration

(

void

)

Parse a variable declaration statement into an AST.

Variable Documentation

operatorPrecedence

TokenType operatorPrecedence[]

static

Initial value:

= {
    [T_PLUS] = 12,  [T_MINUS] = 12, [T_STAR] = 13, [T_SLASH] = 13, [T_EXPONENT] = 15,

    [T_EQ] = 9,     [T_NEQ] = 9,

    [T_LT] = 10,    [T_GT] = 10,    [T_LE] = 10,   [T_GE] = 10,

    [T_AND] = 6,    [T_OR] = 4,     [T_XOR] = 5,   [T_NAND] = 6,   [T_NOR] = 4,       [T_XNOR] = 5,

    [T_ASSIGN] = 2,
}

Operator precedence values. Precedence ranges from 0-15, 15 being the first to be computed.

rightAssociativeOperators

TokenType rightAssociativeOperators[TOKENTYPE_MAX+1]

static

Initial value:

= {
    [T_ASSIGN] = 1,
}
